13-15 3500-14 2500 Ram 4-Link conversionersion

---

The system comes equipped with high-quality urethane bushings which replace the factory rubber and provide a more stable steering wheel sensation both on and off the road. This bolt-on upgrade utilizes high-strength 1/4-inch steel brackets and massive 2 inch diameter tube control arms. For the best suspension system capable of handling the most demanding environments opt for a BDS 4-Link system to upgrade your Ram 2500/3500 Truck.

• Works with 4-6" of liftIncludes complete bolt-on control arm mounting system
• Oversize high performance greaseable urethane bushings
• Massive 2" dia. x .25" wall upper and lower control armsIncludes complete bolt-on control arm mounting system.
• Maintains consistent caster angle through full wheel travel for optimal handling characteristics

---

Information:

6.4L Gas models will require exhuast modification to clear the front driveshaft and passenger side 4-link bracket. 5.7L gas models may require modification - but not in all cases. The vehicle can be driven without the front driveshaft to an exhaust shop for modification and reinstalled This kit does not include a front driveshaft spacer which will be required due to the axle being pushed further forward for improved tire clearance. This driveshaft spacer is included in all BDS indexing rings which is included with all kits 6” and larger. If upgrading from a 4” radius arm drop kit this spacer must be purchased separately. It is acceptable to drive the vehicle without a front driveshaft in place if one needs to be ordered. The trackbar bracket included in BDS radius arm drop brackets is not the same as 4-link kits. This bracket is offset further forward for increased clerance to the differential under full compression since the axle is moved further forward with this kit. The 4-link specific trackbar bracket is highly recommended.

---

Application Summary:

Year	Make/Model
2014-2018	Ram 2500
2013-2018	Ram 3500
