2017-2024 F250 Adjustable front shocks Track Bar
Adjustments are made at the 1-3/8" x 12 fine-threaded center turnbuckle with pinch-bolt ends to allow easy tuning to properly recenter the front axle for a range of lift heights. Track bar is formed for proper clearance around critical front-end components designed to easy installation without the need to clear the factory frame and axle mounts. Both ends use high-durometer polyurethane bushings with thick-walled steel sleeves for strength and reliability.
- Heavy-duty 1-3/8 solid stock steel construction
- Center pinch-bolt style turnbuckle adjustment
- Allows front axle to be recentered at a wide range of lift heights
- Specially formed to alleviate stress on mount points
- Ready to install without need to clear factory frame/axle mounts
Information:
4"-8" with replacement extended track bar bracket
Application Summary:
| Year |
Make/Model |
| 2017-2022 |
Ford F-250 Super Duty |
| 2017-2022 |
Ford F-350 Super Duty |
| Attributes |
| Adjustable |
Yes |
| Bushings Included |
Yes |
| California Proposition 65 |
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Country of Origin (Primary) |
US |
| GTIN |
00711745604056 |
| Hazardous Material Code |
N |
| Installation Time |
1 Hr |
| Life Cycle Status Code |
Available Only While Supplies Last |
| Lift Height |
0_8 |
| Material |
Steel |
| Mounting Hardware Included |
No |
| NAFTA Preference Criterion Code |
B |
| Pvg Product Status |
Active |
| SDR Required Flag |
N |
