60mm Shock Absorber
Bilstein B8 8100 reservoir shock absorbers are a large bore 2.65-in OD direct fit solution for lifted trucks and SUVs. Constructed from aerospace quality billet components, the large 2.65-in OD shock body shock body offers a higher oil volume capacity to control heat while tackling rough road surfaces over long distances. Each B8 8100 offers a unique remote or piggyback reservoir solution for an easy, hassle free installation. These shock absorbers feature a monotube design for consistent fade free performance and utilize velocity sensitive digressive valve settings which are tuned for each specific application. The large 60mm piston design offers more comfort and control in all driving conditions. The Bilstein B8 8100 will allow you to tame the terrain in comfort.
- 60mm large bore digressive piston offers a greater range of tunability and delivers exceptional comfort without sacrificing control
- Direct fit for an easy installation
- 60mm remote reservoir offers increased oil capacity for consistent performance over rough terrain
Application Summary:
| Year |
Make/Model |
| 2020-2025 |
Jeep Gladiator |
| Attributes |
| Adjustable Damping |
Non-Adjustable |
| Adjustable Rebound |
No |
| Body Design |
Smooth Body (Non-Coilover) |
| Body Diameter (ID) |
60mm |
| Body Diameter (OD) |
2.65 in. |
| Boot Included |
No |
| California Proposition 65 |
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Collapsed Length (IN) |
17.57 |
| Collapsed Length (MM) |
446.3 |
| Compressed Length |
17.57 |
| Country of Origin (Primary) |
US |
| Emission Code |
Legal US |
| Extended Length |
29.33 |
| Extended Length (IN) |
29.33 |
| Extended Length (MM) |
745.0 |
| FAB |
60mm large bore digressive piston offers a greater range of tunability and delivers exceptional comfort without sacrificing control, Direct fit for an easy installation |
| Finish |
EVO Grey |
| Grade Type |
Performance |
| Harmonized Tariff Code (Schedule B) |
8708800050 |
| Hazardous Material Code |
N |
| Internal Design |
Monotube |
| Life Cycle Status Code |
Available to Order |
| Lower Mount Type |
Eye 14.1mm |
| Mounting Hardware Included |
Yes |
| PartType |
Shocks / Struts |
| Piston Diameter |
60mm |
| Reservoir |
Yes |
| SDR Required Flag |
Y |
| SDS Sheet Number |
USA SDS_Shock_Air Spring_V2_EN.pdf |
| Segment |
Light Truck |
| Series |
B8 8100 |
| Shaft Diameter |
18mm |
| Spring Seat Included |
No |
| Travel Length |
11.76 |
| Upper Mount Type |
Eye 14.1mm |
| Warranty Time |
24 |
| GTIN |
00651860911472 |
