46mm Monotube Shock Absorber
Bilstein SNS2 Series (BV) shock absorbers feature an all-steel smooth body construction with 46mm internal bore (piston and piston band sold separately, base valve assembly and premium Teflon heims. These shock absorbers include a steel body with external nitrogen fill valve and can be converted to a coilover application (kit sold separately). SNS2 Series (BV) shock absorbers are ideal for racers competing within sanctioning rules require all-steel body construction who are looking for rebuildable dampers with extra tuning options through base valve technology.
- Base Valve design delivers ultra low rod pressures and elminates gas preload
- Modular steel body design allows racer rebuildability
- Comes with IMCA-legal plug assembly installed (SNS2 Series)
Application Summary:
| Year |
Make/Model |
| No |
Applications |
| Attributes |
| Adjustable Damping |
Non-Adjustable |
| Body Design |
Smooth Body Screw Top (Non-coilover) |
| Body Diameter (ID) |
46mm |
| Body Material |
Steel |
| Boot Included |
No |
| California Proposition 65 |
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Collapsed Length (IN) |
13.35 |
| Collapsed Length (MM) |
339.1 |
| Country of Origin (Primary) |
US |
| Emission Code |
Legal US |
| Extended Length (IN) |
19.16 |
| Extended Length (MM) |
486.7 |
| Finish |
Zinc Plated |
| GTIN |
00651860895765 |
| Harmonized Tariff Code (Schedule B) |
8708800050 |
| Hazardous Material Code |
N |
| Internal Design |
Monotube |
| Life Cycle Status Code |
Available to Order |
| Lower Mount Type |
1/2in Heim |
| PartType |
Shocks / Struts |
| Piston Type |
Digressive |
| SDR Required Flag |
Y |
| SDS Sheet Number |
USA SDS_Shock_Air Spring_V2_EN.pdf |
| Segment |
Motorsports |
| Series |
SNS2 Series (BV) |
| Spring Seat Included |
No |
| Upper Mount Type |
1/2in Heim |
| Valving Identifier |
RF PORTSMOUTH |
| Warranty Time |
3 |
