CURT 48011 SecureLatch Adjustable Pintle Mount Plate; 2-Inch Shank; 20;000 Pounds

---

The CURT SecureLatch pintle mount offers easy, precise vertical adjustment of your pintle hitch. It features a unique slotted design that allows the double bolts to slide up and down as needed to level your trailer. Instead of having to disassemble and reassemble the entire hitch, simply loosen the bolts with a single wrench, enough to allow the pintle hitch to slide freely. Then, retorque the bolts -- the bolts provide 48,000 pounds of clamp pressure for highly secure towing of heavy-duty loads. This SecureLatch pintle mount fits any industry-standard 2-inch receiver and has a 9-1/2-inch x 5-inch plate for a wide range of adjustment (NOTE: Never exceed the lowest weight capacity of any towing component; i.e. the vehicle, hitch, trailer, etc). The mount is rated for 20,000 pounds gross trailer weight, and it can accept a SecureLatch pintle hook or ball and pintle combination (sold separately). This pintle mount is constructed from cast steel for superior strength and wear resistance, and it comes with a teridium powder coat finish for lasting corrosion resistance.

• Quick Easy One-Tool Height Adjustments No Disassembly Required
• Textured Dark Grey Teridium Finish For A Premium Look
• Gold Zinc-Plated Hardware For Long-Lasting Corrosion Resistance
• Limited Lifetime Warranty
• Torqued Bolt Plates Provide 48000 lbs. Total Clamp Load
• Accepts Securelatch Pintle Hooks And Ball Hitches
• 10 5/8 High x 5 in. Wide Plate For Versatile Height Adjustment
• Tested And Rated For 24000 lbs. Gross Trailer Weight
• Fits Trailer Hitches With A 2x2 in. Receiver Tube Opening
• Cast Iron Construction Is Austempered For Superior Strength

---

Information:

Slotted bolt plate provides max adjustability, instead of fixed height positions; Quick, easy, one-tool height adjustments -- no disassembly required; Torqued bolt plates provide 48,000 lbs. total clamp load for secure connection; Accepts SecureLatch pintle hooks and ball hitches (sold separately); 9-1/2 high x 5 wide plate for versatile height adjustment; Tested and rated for 20,000 lbs. gross trailer weight; Fits trailer hitches with a 2 x 2 receiver tube opening; Cast steel construction for superior strength and wear resistance; Textured, dark grey teridium powder coat for a premium finish; Bright gold zinc-plated hardware for long-lasting corrosion resistance; Limited lifetime warranty (one-year finish, one-year parts); SecureLatch Adjustable Pintle Mount (2 Shank, 20,000 lbs.)

---

Application Summary:

Year	Make/Model
CURT	48011 SecureLatch Adjustable Pintle Mount Plate, 2-Inch Shank, 20,000 Pounds
