ORACLE Lighting Jeep Wrangler JL/Gladiator JT 7in. High Powered LED Headlights (Pair)
The Ultimate LED replacement headlight option for any vehicle with 7 Sealed Beam lamps. The rugged design is perfect for your Jeep Wrangler, Off-Road Vehicle, Buggies, or Classic Car/ Truck. Installation is very easy with the included H4 and H13 Plug and Play connectors. Each set comes in full color retail-ready packaging and a 2-Year free Replacement Warranty. You can even choose optional colored Halos for even more customization! Improvements in brightness and reliability by adding a constant current LED driver to the main circuit board inside of the lamp to control the halos. NEW! No need for Anti-Flicker Wiring Adapters- The new SMART Integrated Can-Bus system automatically adjusts- preventing flicker issues. Increased Reliability- By conditioning the power going into the LEDs this prevents degradation which can shorten the overall lifespan of the product. Wider Input Voltage Range- The new SMD Halos can operate on a very wide voltage range from 12V-24V so that voltage spike can not damage the LEDs. Brighter LED Halos- by moving the heat load of the resistors off the PCB we are able to increase the number of LEDs on the circuit board without thermal issues. LED chips upgraded from a Cree LED to a Phillips Luxeon ZES chip.They deliver a very high efficacy 130LM/W ratio while having lower thermal output.
- Premium Performance Phillips Luxeon ZES LEDs
- Die-Cast Housing with Corrosion Resistant Coating
- Hard-coated Polycarbonate Lens
- Optional: ORACLE Halo Rings Pre-Installed
Information:
White
Application Summary:
| Year |
Make/Model |
| 2020-2024 |
Jeep Gladiator |
| 2018-2024 |
Jeep Wrangler |
| Attributes |
| Add-On |
N/A |
| Amp Draw |
2.50 Amps at 12V DC / 1.30 Amps at 24V DC |
| California Proposition 65 |
WARNING: Cancer - www.P65Warnings.ca.gov |
| Color |
White |
| Color Temperature |
6000K |
| Contents |
(2x) ORACLE 7in. High Performance LED Headlights, (2x) Plug & Play Wiring Adapters, (2x) Direct-Fit Beam Adjustable Headlight Brackets |
| Country of Origin (Primary) |
US |
| GTIN |
00810030390497 |
| Harmonized Tariff Code (Schedule B) |
8512200000 |
| Hazardous Material Code |
N |
| High Beam Lumens |
3600 |
| High Beam Wattage |
40W Normal/48W Max |
| Kelvin Temperature |
6000K |
| LED Color |
White |
| Life Cycle Status Code |
Available to Order |
| Low Beam Lumens |
2200 |
| Low Beam Wattage |
30W Normal/36W Max |
| NAFTA Preference Criterion Code |
B |
| SDR Required Flag |
N |
| SDS Sheet Number |
N |
| Voltage |
12-24V DC |
| Warranty |
2 Year |
| Warranty Time |
2 |
