Bolt-On Arm Lift Kit; 3 in.; Tubular Upper Control Arms; Cleveite Rubber Bushings; Fabricated Rear Blocks; Includes N3 Lifted Struts; Nitrogen Charged Shocks Absorbers;
Rough Countrys 3in Bolt-On Kit offers easy installation and aggressive good looks at an incredible value. Take your truck to new heights with this excellent option for 09 and up F-150 pickups.This kit features a set of high-quality, tubular Upper Control Arms designed to make alignment adjustments easier and Clevite rubber bushings for enhanced durability. These arms are designed to promote a factory-like geometry by keeping the ball joint at optimum angles after lifting. This design allows for an improved, greater range of motion from the ball-joint, with less stress, wear and tear.Rough Countrys 3- in. Bolt-On Kit features N3 Nitrogen-charged shocks, giving your truck incredible ride-quality both on and off-road. Also included are a set of durable lifted struts and fabricated rear blocks to provide lift height from front to rear. Once installed, this kit gives your truck plenty of ride height for up to 34in tires while offering a clean, level look from front to rear. Retain your stock wheels with this kit when you use Rough Countrys 0.25- in. wheel spacer.This all-inclusive kit comes with everything you need, and installation is a piece of cake compared to other kits on the market! Featuring a 100% bolt-on installation process that requires zero cutting or drilling, this kit can be installed using common tools in a home garage, and allows the truck to be returned to stock at any time if so desired. Best of all this kit features Rough Countrys Lifetime Replacement Warranty.
- 10-Stage Variable Valving
- Control Arms Include Clevite Rubber Bushings For More Durability
- Levels The Front And Rear Of The Truck
- Can Be Returned To Stock
- Retain Your Factory Wheels By Using Our 0.25 in. Wheel Spacers
- Lifetime Replacement Warranty
- High Pressure Nitrogen Charged
- No Cutting Or Drilling Required
- Includes New Tubular Upper Control Arms
- Control Arms Keep Ball Joints At Optimum Angles
Information:
Vehicles with factory ride height over 22in may not receive a full 3in of lift
Application Summary:
| Year |
Make/Model |
| 2009-2013 |
Ford F-150 |
| Attributes |
| California Proposition 65 |
No |
| Country of Origin (Primary) |
CN |
| Front Components |
(2) Upper control arms, (2) Loaded, Lifted Struts |
| Front Kit Componenets |
(2) Upper control arms, (2) Loaded, Lifted Struts |
| Front Kit Components |
(2) Upper control arms, (2) Loaded, Lifted Struts |
| GTIN |
00843030169633 |
| Harmonized Tariff Code (Schedule B) |
8708809900 |
| Hazardous Material Code |
N |
| Install Time |
5-6 hours |
| Life Cycle Status Code |
Available to Order |
| Lift/Drop Height |
3 in., 1 in. |
| NAFTA Preference Criterion Code |
B |
| Rear Components |
(2) Lift Blocks, (4) U-bolts, Hardware |
| Rear Kit Components |
(2) Lift Blocks, (4) U-bolts, Hardware |
| SDR Required Flag |
N |
| Tire & Wheel Size Combinations |
295/60 R20 - 20x9, Offset: +12mm, 295/60 R20 - 20x9, Offset: +12mm |
| Tire, Wheel, and Offset Info |
33x12.50R17:17x8.5:6x135:+0:Minor trimming; 33x12.50R17:17x8.5:6x135:+1:Minor trimming; 33x12.50R17:17x9:6x135:+0:Minor trimming; 33x12.50R17:17x9:6x135:+1:Minor trimming; 33x12.50R17:17x9:6x135:+12:Minor trimming; 33x12.50R18:18x8.5:6x135:+0:Minor trimming; 295 70R18:18x8.5:6x135:+0:Minor trimming; 33x12.50R18:18x8.5:6x135:+1:Minor trimming; 295 70R18:18x8.5:6x135:+1:Minor trimming; 33x12.50R18:18x9:6x135:+0:Minor trimming; 295 70R18:18x9:6x135:+0:Minor trimming; 33x12.50R18:18x9:6x135:+1:Minor trimming; 295 70R18:18x9:6x135:+1:Minor trimming; 33x12.50R18:18x9:6x135:+12:Minor trimming; 295 70R18:18x9:6x135:+12:Minor trimming; 33x12.50R20:20x9:6x135:+0:Minor trimming; 305 55R20:20x9:6x135:+0:-; 295 60R20:20x9:6x135:+0:Minor trimming; 33x12.50R20:20x9:6x135:+1:Minor trimming; 305 55R20:20x9:6x135:+1:-; 295 60R20:20x9:6x135:+1:Minor trimming; 33x12.50R20:20x9:6x135:+12:Minor trimming; 295 60R20:20x9:6x135:+12:Minor trimming |
