4-Link Suspension Lift Kit w/Shocks; 6 in. Lift;
Compliment your 08-10 Ford F-250/350s aggressive, good looks with Rough Countrys 4-Link Suspension Lift System. Rough Countrys 8- in. Lift Kit was engineered to retain the F-250/350s impressive factory specs while bumping up performance and durability where its needed most. The result is an aggressive, lifted beast with a mean profile and balanced on and off-road ride quality. When changing a vehicles suspension, the key to preserving ride quality is in keeping the geometry of all suspension components as close to their factory angles as possible. Rough Countrys 4-Link Suspension Lift System features a set of ultra-durable radius arm drop brackets, precision fit to bolt right into the factory mounts for an easier install and a more factory-like angle. This all-inclusive kit also features an adjustable lower control arms at the axle to allow caster adjustment as well as a track bar relocation bracket and a drop pitman arm. A full set of N3 Shocks provide a truly balanced ride quality for on and off-road use - prefect for daily drivers. This kit also ships with a set of durable, lifted coil springs and brake line relocation brackets. This innovative kit design features a 100% bolt-on installation process that is lightning fast compared to other kits this size. Save time and money with no need for cutting, drilling, or other complicated procedures. Rough Countrys Rough Countrys 4-Link Suspension Lift System is backed by our Lifetime Replacement Warranty.
- Easy Bolt-On Installation
- Increased Ground Clearance
- Levels The Front w/The Rear Of The Vehicle
- Radius Arm Drop Brackets Allow For Properly Set Caster
- Proper Caster Is Crucial
- To Maintaining Factory Handling And Drivability
- Incl. Application Valved N3 Series Shock Absorbers
- Offer The Best In Balanced Performance For On And Off-road Use
Information:
Manufacturer: Rough Country Suspension Systems; Part Number: 584.20; Weight (Lbs): 251.78; Install Time (Hours): 6-8; Recommended Tire Size: 37-by-13.50
Application Summary:
| Year |
Make/Model |
| 2008-2010 |
Ford F-250 Super Duty |
| 2008-2010 |
Ford F-350 Super Duty |
| Attributes |
| California Proposition 65 |
No |
| Country of Origin (Primary) |
US |
| Front Components |
Lifted coil springs, Fixed upper control arms, Adjustable lower control arms, Radius arm drop brackets, Extended sway-bar links, Track bar drop bracket, Stabilizer relocation brackets, Pitman arm, Stainless steel braided brake lines, Bumpstop spacers, Hardware |
| Front Kit Componenets |
Lifted coil springs, Fixed upper control arms, Adjustable lower control arms, Radius arm drop brackets, Extended sway-bar links, Track bar drop bracket, Stabilizer relocation brackets, Pitman arm, Stainless steel braided brake lines, Bumpstop spacers, Hardware |
| GTIN |
00843030127305 |
| Harmonized Tariff Code (Schedule B) |
8708809900 |
| Hazardous Material Code |
N |
| Install Time |
6-8 hours |
| Life Cycle Status Code |
Available to Order |
| Lift/Drop Height |
6 in. |
| NAFTA Preference Criterion Code |
B |
| Rear Components |
3in lift blocks, Add-a-leafs, Carrier bearing drop bracket, U-bolts, Hardware |
| Rear Kit Components |
3in Lift Blocks, Add-a-Leafs, Carrier bearing drop bracket, U-Bolts, Hardware |
| SDR Required Flag |
N |
| Tire, Wheel, and Offset Info |
37x13.50R17:17x9:8x170:-12:-; 37x13.50R17:17x9:8x170:+0:-; 37x13.50R17:17x9:8x170:+1:-; 37x13.50R18:18x9:8x170:-12:-; 37x13.50R18:18x9:8x170:+0:-; 37x13.50R18:18x9:8x170:+1:-; 37x13.50R20:20x9:8x170:-12:-; 37x13.50R20:20x9:8x170:+0:-; 37x13.50R20:20x9:8x170:+1:-; 37x12.50R20:20x10:8x170:-25:-; 37x12.50R20:20x10:8x170:-24:-; 37x12.50R20:20x10:8x170:-19:-; 37x12.50R20:20x10:8x170:-18:-; 37x12.50R20:20x12:8x170:-44:Trimming Required; 37x12.50R22:22x10:8x170:-25:-; 37x12.50R22:22x10:8x170:-24:-; 37x12.50R22:22x10:8x170:-19:-; 37x12.50R22:22x10:8x170:-18:-; 37x12.50R22:22x12:8x170:-44:Trimming Required |
