X-Series Suspension Lift Kit w/Shocks; 2.5 in. Lift;
Venture far beyond the limits of a stock Wrangler with Rough Countrys all-inclusive 2.5- in. X-Series Lift for Jeep TJ. Level the front of your vehicle with the rear while gaining enough increased ground clearance to run up to 33- in. tires. Rough Countrys X-Series line represents the best-in-class equipment for off-road action, including fully rebuildable X-Flex Adjustable Control Arms, Clevite Rubber Bushings, Sway-bar quick disconnects, and your choice of our N3 shocks for daily drivers or our oversized Performance 2.2s for optimum off-road performance. For those who are serious about flexing, crawling, and pushing your Jeep to the limits, this kit features an upgraded Forged Adjustable Track Bar. Made of forged steel, this 16lb Track Bar boasts a beefy construction that will dwarf stock equipment. Easy to install and fully adjustable on the vehicle.
- Easy Bolt-On Installation
- Feature High Clearance Design
- Extreme Travel Long Arms
- Keep Optimum Alignment And Give Optimum Articulation
- X-flex Control Arm Features
- Increased Ground Clearance
- Levels The Front w/The Rear Of The Vehicle
- Front Adjustable Track Bar Is Made Of Forged Solid Steel
- For Unsurpassed Strength And Durability
- Quick Disconnects Quickly
- Easily Store Out Of The Way When Not In Use
- Lower Control Arms
Information:
Manufacturer: Rough Country Suspension Systems; Part Number: 61220; Weight (Lbs): 151.39; Install Time (Hours): 2-3; Wheel Backspacing (Inches): Factory; Recommended Tire Size: 31-by-10.50
Application Summary:
| Year |
Make/Model |
| 1997-2006 |
Jeep TJ |
| 1997-2006 |
Jeep Wrangler |
| Attributes |
| California Proposition 65 |
No |
| Country of Origin (Primary) |
US |
| Front Components |
Lifted coil springs, Upper adjustable control arms, Lower adjustable control arms, Sway-bar quick disconnects, Forged adjustable track bar, Hardware |
| Front Kit Componenets |
Lifted coil springs, Upper adjustable control arms, Lower adjustable control arms, Sway-bar quick disconnects, Forged adjustable track bar, Hardware |
| Front Kit Components |
Lifted coil springs, Upper adjustable control arms, Lower adjustable control arms, Sway-bar quick disconnects, Forged adjustable track bar, Hardware |
| GTIN |
00843030124632 |
| Harmonized Tariff Code (Schedule B) |
8708809900 |
| Hazardous Material Code |
N |
| Install Time |
6-8 hours |
| Life Cycle Status Code |
Available to Order |
| Lift/Drop Height |
2.5 in. |
| NAFTA Preference Criterion Code |
B |
| Rear Components |
Lifted coil springs, Upper adjustable control arms, Lower adjustable control arms, Track bar drop bracket, Hardware |
| Rear Kit Components |
Lifted coil springs, Upper adjustable control arms, Lower adjustable control arms, Track bar drop bracket, Hardware |
| SDR Required Flag |
N |
| Tire, Wheel, and Offset Info |
31x10.50R15:15x8:5x4.5:-19:-; 31x10.50R15:15x8:5x4.5:-18:-; 31x10.50R15:15x8:5x4.5:-12:-; 31x10.50R15:15x8:5x4.5:-6:-; 265 70R16:16x8:5x4.5:-19:-; 265 70R16:16x8:5x4.5:-18:-; 265 70R16:16x8:5x4.5:-12:-; 265 70R16:16x8:5x4.5:-6:-; 265 65R17:17x8:5x4.5:-19:-; 265 65R17:17x8:5x4.5:-18:-; 285 70R17:17x8.5:5x4.5:-12:-; 285 70R17:17x8.5:5x4.5:+0:-; 265 65R17:17x8.5:5x4.5:+0:-; 265 65R17:17x8.5:5x4.5:+1:-; 285 70R17:17x9:5x4.5:-12:-; 265 65R17:17x9:5x4.5:-12:-; 265 65R17:17x9:5x4.5:+0:-; 285 70R17:17x9:5x4.5:+1:-; 265 65R17:17x9:5x4.5:+1:-; 265 60R18:18x8:5x4.5:-19:-; 265 60R18:18x8:5x4.5:-18:-; 265 60R18:18x8.5:5x4.5:+0:-; 265 60R18:18x8.5:5x4.5:+1:-; 265 60R18:18x9:5x4.5:-12:-; 265 60R18:18x9:5x4.5:+0:-; 265 60R18:18x9:5x4.5:+1:-; 275 55R20:20x8:5x4.5:-19:-; 275 55R20:20x8:5x4.5:-18:-; 305 55R20:20x9:5x4.5:-12:-; 285 55R20:20x9:5x4.5:-12:-; 275 55R20:20x9:5x4.5:-12:-; 275 55R20:20x9:5x4.5:+0:-; 275 55R20:20x9:5x4.5:+1:-; 33x12.50R20:20x10:5x4.5:-19:-; 305 55R20:20x10:5x4.5:-19:-; 285 55R20:20x10:5x4.5:-19:-; 33x12.50R20:20x10:5x4.5:-18:-; 305 55R20:20x10:5x4.5:-18:-; 285 55R20:20x10:5x4.5:-18:- |
