Suspension Lift Kit w/Shock; 6 in. Lift;
You'll never look at a Tacoma the same way after installing Rough Country's 6in Toyota Tacoma kit. This all-inclusive kit is a total transformation for your truck, with durable lifted knuckles, front and rear crossmembers, fabricated lift blocks, and all the brackets and hardware needed to set your truck to a factory-like geometry while providing additional ground clearance. Run up to 33 x 12.50 tires while giving your truck a one-of-a-kind look and exceptional off-road performance. This kit affords your truck an aggressive appearance and a higher profile that is sure to demand attention. This kit includes Rough Country's Nitrogen-charged N3 Shocks for the ultimate balance in highway ride quality and off-road vibration dampening. Includes Rough Country's Lifetime Replacement Guarantee.
- Increased ground clearance
- No strut disassembly or strut compressor required for installation
- Features application valved N3 series shock absorbers which offer the best in balanced performance for on and off-road use
- Fabricated blocks are stronger and offer a longer lifespan than cast blocks.
Information:
Requires cutting and drilling. Does NOT fit T/X Baja models. Does NOT fit XSP-X models. Requires aftermarket wheels - Does NOT work with factory wheels.
Application Summary:
| Year |
Make/Model |
| 2016-2023 |
Toyota Tacoma |
| Attributes |
| California Proposition 65 |
WARNING: Cancer - www.P65Warnings.ca.gov |
| Category |
Susp Lift Kits 4wd |
| Country of Origin (Primary) |
US |
| Front Components |
Lifted knuckles, Strut spacers, Front crossmember, Rear crossmember, Front skid plate, Lower skid plate, Differential drop brackets, Steering stops, Bumpstops, Bumpstop extensions, Sway-bar relocation brackets, Brake line brackets, Hardware |
| Front Kit Componenets |
Lifted knuckles, Strut spacers, Front crossmember, Rear crossmember, Front skid plate, Lower skid plate, Differential drop brackets, Steering stops, Bumpstops, Bumpstop extensions, Sway-bar relocation brackets, Brake line brackets, Hardware |
| Front Kit Components |
Lifted knuckles, Strut spacers, Front crossmember, Rear crossmember, Front skid plate, Lower skid plate, Differential drop brackets, Steering stops, Bumpstops, Bumpstop extensions, Sway-bar relocation brackets, Brake line brackets, Hardware |
| GTIN |
00843030124205 |
| Harmonized Tariff Code (Schedule B) |
8708809900 |
| Hazardous Material Code |
N |
| Install Time |
6-8 hours |
| Life Cycle Status Code |
Available to Order |
| Lift/Drop Height |
6 in. |
| NAFTA Preference Criterion Code |
B |
| Rear Components |
4.5in Fabricated lift blocks, U-bolts, Carrier bearing shims, Brake line brackets, Hardware |
| Rear Kit Components |
4.5in Fabricated Lift Blocks, U-Bolts, Carrier bearing shims, Brake line brackets, Hardware |
| SDR Required Flag |
N |
| Shipping Options |
No Restrictions |
| Ships in Multiple Boxes |
Y |
| Tire & Wheel Size Combinations |
33x12.50 R17 - 17x9, Backspacing: 4.5-5in, 33x12.50 R17 - 17x9, Backspacing: 4.5-5in |
| Tire, Wheel, and Offset Info |
33x12.50R17:17x8.5:6x5.5:+0:-; 285 70R17:17x8.5:6x5.5:+0:-; 33x12.50R17:17x8.5:6x5.5:+1:-; 33x12.50R17:17x9:6x5.5:-12:-; 285 70R17:17x9:6x5.5:-12:-; 33x12.50R17:17x9:6x5.5:+0:-; 285 70R17:17x9:6x5.5:+0:-; 33x12.50R17:17x9:6x5.5:+1:-; 285 70R17:17x9:6x5.5:+1:-; 33x12.50R18:18x8.5:6x5.5:+0:-; 33x12.50R18:18x8.5:6x5.5:+1:-; 33x12.50R18:18x9:6x5.5:-12:-; 285 65R18:18x9:6x5.5:-12:-; 33x12.50R18:18x9:6x5.5:+0:-; 285 65R18:18x9:6x5.5:+0:-; 33x12.50R18:18x9:6x5.5:+1:-; 285 65R18:18x9:6x5.5:+1:-; 33x12.50R20:20x9:6x5.5:-12:-; 305 55R20:20x9:6x5.5:-12:-; 285 55R20:20x9:6x5.5:-12:-; 33x12.50R20:20x9:6x5.5:+0:-; 305 55R20:20x9:6x5.5:+0:-; 285 55R20:20x9:6x5.5:+0:-; 33x12.50R20:20x9:6x5.5:+1:-; 305 55R20:20x9:6x5.5:+1:-; 285 55R20:20x9:6x5.5:+1:-; 33x12.50R20:20x10:6x5.5:-25:Minor Trimming; 305 55R20:20x10:6x5.5:-25:-; 285 55R20:20x10:6x5.5:-25:-; 33x12.50R20:20x10:6x5.5:-24:Minor Trimming; 305 55R20:20x10:6x5.5:-24:-; 285 55R20:20x10:6x5.5:-24:-; 33x12.50R20:20x10:6x5.5:-19:Minor Trimming; 305 55R20:20x10:6x5.5:-19:Minor Trimming; 285 55R20:20x10:6x5.5:-19:-; 33x12.50R20:20x10:6x5.5:-18:Minor Trimming; 305 55R20:20x10:6x5.5:-18:Minor Trimming; 285 55R20:20x10:6x5.5:-18:-; 33x12.50R22:22x10:6x5.5:-25:Minor Trimming; 33x12.50R22:22x10:6x5.5:-19:Minor Trimming |
