BantamX - Jeep 2009-2018 Wrangler JK (Color: Blue)

---

FEATURES AVAILABLE THROUGH sPOD MOBILE APP (free): Each switch can be programmed for: Dimming. Strobe. Flash. Momentary. Switch Linking. On Road and Off Road mode of operationThe following features are only available through the purchase of our Pro-Series App: Circuit timers. Switch lockout. Initial startup current for each circuit is raised to 65amps for 5 seconds. Program any circuit to be always on while still maintaining fault protection. Option to disable deep sleep mode. Selectable auto restart after circuit shuts down from over current/short. Programmable Current Limiting (in 2amp increments up to 30amps). Selectable auto restart for current limiting shut down. Selectable "Latch" or "Momentary" actions for inputs. Programmable ignition control for all 8 circuits. Variable strobe function to create custom flash/strobe patternsEXTERNAL CONTROLLER OPTIONS (not included with system and can only be used in conjunction with an sPOD controller). Third party switches. Computers. Arduino. Raspberry Pi. Alpine Audio systems KAC-001 head unit controller. Sensors, thermostats, pressure switches, fan controllers and more----SWITCH PANEL Switch panel with eight dual lit LED Blue switches (installed and pre-wired)All wires are wrapped in high-temp abrasion resistant nylon braided sleeving. Comes with a 10 foot CAT-6 Ethernet, can be extended up to 25-feet from BantamX)Aluminum panels are formed, welded and powder coated Carling Technologies Contura switches (certified to IP66/68 - marine/harsh environment)Controlled lower pilot light (push button)Custom laser-etched rockers are availableAbility to daisy chain panels for remote operations (ie: panel in cab and panel at rear of truck)Auto safe system shutdown when panel is unpluggedCan run in conjunction with another 8-Switch panel, HD and Touchscreen.

• Due to the small footprint of the BantamX, the placement options are endless! No cutting, fishing wires into the cab or tapping into the vehicle‘s electrical system

---

Information:

BantamX

---

Application Summary:

Year	Make/Model
2009-2018	Jeep Wrangler
